Solar Street Light Pole
Features
Our solar street light pole is a structure designed to hold solar panels and light fixtures in order to provide lighting on streets, roads, and other outdoor areas. It typically consists of a tall pole made of steel, with a solar panel mounted at the top to absorb sunlight and convert it into electricity. The electricity is then stored in a battery or used to power LED light fixtures mounted on the pole for illumination during the night. Solar led street light pole and solar powered street light post are an eco-friendly and cost-effective alternative to traditional street lighting systems that rely on electricity from the grid.
Datasheet
We have various solar powered street light post height range from 4M-12M,but 6M to 12M pole is more common in the market.
And the shape is conical or octagonal are accepted,here is stand diameter sheet for choosing,surely,customized size is available:
|
Height (H) |
Top OD (d) |
Bottom OD (D) |
Thickness (T) |
Door Size (mm) optional |
Base Plate (L×W×T) |
Plate Specs （mm） |
Wight(kgs) |
|
6m-19ft |
60mm |
150mm |
3.0mm |
80×200 |
260*12 |
695mm |
55.5 |
|
7m-23ft |
60mm |
165mm |
3.25mm |
100×200 |
260*14 |
695mm |
69.5 |
|
8m-26ft |
76mm |
170mm |
3.5mm |
100×200 |
320*16 |
760mm |
96.4 |
|
9m-29ft |
76mm |
170mm |
3.75mm |
120×260 |
320*16 |
760mm |
113.5 |
|
10m-33ft |
80mm |
205mm |
4.0mm |
120×260 |
350*18 |
875mm |
154.7 |
|
11m-36ft |
80mm |
205mm |
4.0mm |
120×350 |
350*18 |
875mm |
168.4 |
|
12m-39ft |
100mm |
205mm |
4.0mm |
120×350 |
400*200 |
1020mm |
217.2 |
|
REMARK:1,Above dimension is common stand for solar LED street light pole,other dimension is available. 2,Customized dimension is available. 3,Electric street light pole with smaller dimension. |
|||||||
More Designs
Forever Lighting providing various solar led street light pole designs include single arm solar street light poles,double arm solar street light pole,pls contact us regarding your specific requirements from now:
Finished Poles
Production Priority
Hot Tags: solar street light pole, China solar street light pole manufacturers, suppliers, factory, octagonal light pole, street light lamp post outdoor, cost of street light pole, solar led street light pole, Square Pole, square steel pole
FAQ:
What is the price of solar street light pole?
The price of a solar street light pole can vary depending on several factors such as the material used, the height and design of the pole, the wattage of the solar panel and LED lights, and any additional features or accessories. As a result, it is difficult to provide an exact price without specific details.So welcome to consult with us to get accurate pricing information based on your specific requirements.
Do solar street lights need electricity?
No, solar street lights do not need electricity from the grid. They are equipped with solar panels that convert sunlight into electricity, which is then stored in batteries. This stored energy is used to power the street lights during the night.
